NBSANMINSE PC58 G NPT 1/4 UF7/16 M12X1.25 1つのスイッチで2つの圧力設定点を持つ空気水中の二重圧力スイッチ
担当者 : Ina Chen
電話番号 : 0086-15168536055
WhatsApp : +8615168536055
| 起源の場所: | 中国 | ブランド名: | NBSANMINSE |
|---|---|---|---|
| モデル番号: | SMF17 |
|
詳細情報 |
|||
| モデル: | SMF17 | サイズ: | NPT 1-4 NPT 3-8 アダプタ |
|---|---|---|---|
| 証明: | ce | 特徴: | 堅固 な 塗装 鋼 |
| 材料: | プラスチック | ||
製品の説明
The rugged SMF17 pressure switch is designed for the demanding requirements of lager, heavy duty commercial air compressors (up to 250 psi). The sturdy painted steel case and cover resists the harsh conditions encountered in industrial applications. This style is also available with an unloader valve to prevent the compressor from starting under load.
Sturdy Stamped Steel Case & Cover Visible Contact
No Drift Pressure Setting Captive Cover nut
Ample Wiring Room 2 Ground Screw
Easy to Adjust Automatic Unloader Valve Available
Pulsation Dampener Standard 5HP Heavy Duty Rating
250 PSI Max
|
MODEL
|
Min ON (Cut-In)PSI
|
Max Off
(Cut-Out) PSI
|
Differential
PSI
|
Factory Setting PSI
|
Electrical Rating
|
Pipe Fittings
|
Contact Arrangement
|
|
|
120VAC
|
240VAC
|
|||||||
|
SMF17
|
40
|
250
|
25-60
|
145-175
|
24A
|
12A
|
1/4", 3/8" Male or Female NPT
|
NC
|
|
SMF17-S
|
15
|
60
|
7-15
|
30-40
|
24A
|
12A
|
1/4", 3/8" Male or Female NPT
|
NC
|
